PREFACE
FEATURES
The Data Multiplex Unit WJ-MP204C is designed for instal-
lation in a surveillance system, offering system flexibility
particularly when camera control functions are required.
The unit multiplexes video signals with control data and
VD2 sync into a coaxial cable. This makes installations
between the unit and cameras easy.
Front Panel Operations
• Camera channel selection from 1 to 4
• Alarm reset/suspension
• WJ-MP204C setup menus
In/Out Features
• Four camera inputs with multiplexed control and VD2
• Four camera outputs looped through
• Spot (monitor) in/out
• VS/VD (sync) in/out
• RS-485 for use of the Camera Communication Protocol
• RS-485 for use of the PS
•
Data protocol
• Alarm in/out and remote in/out, switchable
Displayed Image on the monitor screen
• Camera channel selected
• Alarm channel activated
• Setup menus
Camera control with WV-CU360C
• Pan/tilt head and housing control
• Motorized lens control (focus, zoom, iris, etc.)
• Camera setup menus
Alarm Function
• Inputs: Video Motion Detection by the camera/Alarm
input to the terminal.
• Output: Signal is supplied to respective alarm terminal.
• Preset: The camera moves to the preset position when
an alarm operates.
• Display: The activated channel picture and the channel
number are displayed.
The monitor and system controller can be located distant
from the camera site thanks to the use of a coaxial cable
and an RS-485 cable.
The unit includes two protocols, Panasonic Security Data
(PS
•
Data) and the Camera Communication one, selectable
with DIP switches.
