Accessories / Options
7
Optional accessories
Please contact your local Panasonic dealer to purchase the recommended optional accessories. For additional details,
please read the manual of the optional accessories.
3D Eyewear set
(Rechargeable type)
●
TY-ER3D4MW
●
TY-ER3D4SW
●
If you need additional 3D Eyewear, please purchase this optional accessory.
●
Use Panasonic 3D Eyewear for active 3D supporting Bluetooth wireless technology.
●
For more information:
http://panasonic.net/avc/viera/3d/asia.html
Communication Camera
●
TY-CC20W
●
This camera can be used on VIERA Connect (p. 20, 78).
●
Depending on the area, this optional accessory may not be available.
For details, consult your local Panasonic dealer.
Wall-hanging bracket
●
TY-WK4P1RW (50” class)
●
TY-WK5P1RW (55” / 60” class)
●
TY-WK6P1RW (65” class)
a: 400 mm
b: 300 mm
a: 500 mm
b: 300 mm
a: 684 mm
b: 300 mm
●
Tilting angle for this TV:
0 (vertical) to 10 degrees
●
Tilting angle for this TV:
0 (vertical) to 20 degrees
●
Tilting angle for this TV:
0 (vertical) to 10 degrees
Rear of the TV
Holes for wall-hanging bracket installation
a
b
(View from the side)
Depth of screw:
(50” / 55” class) minimum 10 mm, maximum 16 mm
(60” / 65” class) minimum 17 mm, maximum 23 mm
Type of screw: M8
Screw for fixing the TV onto the wall-hanging bracket (not supplied with
the TV)
Warning
●
Using other wall-hanging brackets, or installing a wall-hanging bracket by yourself have the risk of personal injury and
product damage. In order to maintain the unit’s performance and safety, be absolutely sure to ask your dealer or a
licensed contractor to secure the wall-hanging brackets. Any damage caused by installing without a qualified installer
will void your warranty.
●
Carefully read the instructions accompanying optional accessories, and be absolutely sure to take steps to prevent
the TV from falling off.
●
Handle the TV carefully during installation since subjecting it to impact or other forces may cause product damage.
●
Take care when fixing wall brackets to the wall. Always ensure that there are no electrical cables or pipes in the wall
before hanging bracket.
●
To prevent fall and injury, remove the TV from its fixed wall position when it is no longer in use.
