MAZSxxx Series
SKE00012CED
2
Zener voltage
Reverse Zener operating
current resistance
Part Number V
Z
(V) I
R
(µA) R
Z
(Ω)R
ZK
(Ω)S
Z
(mV/°C) Marking symbol
Min Nom Max
I
Z
Max
V
R
Max
I
Z
Max
I
Z
Typ
I
Z
(mA) (V) (mA) (mA) (mA)
MAZS024 2.28 2.40 2.60 5 120 1.0 100 5 −1.6 5 T
MAZS027 2.50 2.70 2.90 2 or 2_ or 2^
MAZS0270L 2.50 2.60 2.75 5 120 1.0 110 5 −2.0 5 2_
MAZS0270H 2.65 2.80 2.90 2^
MAZS030 2.80 3.00 3.20 3 or 3_ or 3^
MAZS0300L 2.80 2.90 3.05 5 50 1.0 120 5 −2.1 5 3_
MAZS0300H 2.95 3.10 3.20 3^
MAZS033 3.10 3.30 3.50 F or F_ or F^
MAZS0330L 3.10 3.20 3.35 5 20 1.0 130 5 −2.4 5 F_
MAZS0330H 3.25 3.40 3.50 F^
MAZS036 3.40 3.60 3.80 H or H_ or H^
MAZS0360L 3.40 3.50 3.65 5 10 1.0 130 5 −2.4 5 H_
MAZS0360H 3.55 3.70 3.80 H^
MAZS039 3.70 3.90 4.10 K or K_ or K^
MAZS0390L 3.70 3.80 3.97 5 10 1.0 130 5 −2.5 5 K_
MAZS0390H 3.87 4.00 4.10 K^
MAZS043 4.00 4.30 4.60 L or L_ or L− or L^
MAZS0430L 4.03 4.10 4.26
5 10 1.0 130 5 −2.5 5
L_
MAZS0430M 4.17 4.30 4.40 L−
MAZS0430H 4.31 4.40 4.54 L^
MAZS047 4.40 4.70 5.00 N or N_ or N− or N^
MAZS0470L 4.45 4.60 4.69
5 2.0 1.0 80 5 800 1.0 −1.4 5
N_
MAZS0470M 4.59 4.70 4.83 N−
MAZS0470H 4.74 4.90 4.99 N^
MAZS051 4.80 5.10 5.40 5 or 5_ or 5− or 5^
MAZS0510L 4.87 5.00 5.12
5 1.0 2.0 60 5 500 1.0 − 0.8 5
5_
MAZS0510M 5.00 5.10 5.26 5−
MAZS0510H 5.14 5.30 5.40 5^
MAZS056 5.30 5.60 6.00 P or P_ or P− or P^
MAZS0560L 5.30 5.40 5.58
5 0.5 2.5 40 5 200 0.5 1.2 5
P_
MAZS0560M 5.48 5.60 5.76 P−
MAZS0560H 5.66 5.80 5.95 P^
MAZS062 5.80 6.20 6.60 6 or 6_ or 6− or 6^
MAZS0620L 5.85 6.00 6.15
5 0.2 4.0 30 5 100 0.5 2.3 5
6_
MAZS0620M 6.05 6.20 6.36 6−
MAZS0620H 6.24 6.40 6.56 6^
MAZS068 6.40 6.80 7.20 R or R_ or R− or R^
MAZS0680L 6.44 6.60 6.77
5 0.1 4.0 20 5 60 0.5 3.0 5
R_
MAZS0680M 6.64 6.80 6.98 R−
MAZS0680H 6.85 7.00 7.20 R^
MAZS075 7.00 7.50 7.90 7 or 7_ or 7− or 7^
MAZS0750L 7.07 7.30 7.43
5 0.1 5.0 20 5 60 0.5 4.0 5
7_
MAZS0750M 7.29 7.50 7.67 7−
MAZS0750H 7.51 7.70 7.89 7^
MAZS082 7.70 8.20 8.70 8 or 8_ or 8− or 8^
MAZS0820L 7.77 7.90 8.17
5 0.1 5.0 20 5 60 0.5 4.6 5
8_
MAZS0820M 8.03 8.20 8.43 8−
MAZS0820H 8.29 8.50 8.70 8^
MAZS091 8.50 9.10 9.60 9 or 9_ or 9- or 9^
MAZS0910L 8.58 8.80 9.02
5 0.1 6.0 20 5 60 0.5 5.5 5
9_
MAZS0910M 8.87 9.10 9.33 9−
MAZS0910H 9.14 9.40 9.60 9^
■ Electrical characteristics within part numbers T
a
= 25°C±3°C
Temperature
coefficient of
zener voltage
