DEFINITY Enterprise Communications Server Release 7
Maintenance for R7r
555-230-126
Issue 4
June 1999
Maintenance Object Repair Procedures
9-969ISDN-TRK (DS1 ISDN Trunk)
9
To investigate the service state of the DS1 ISDN Trunk, issue the
status trunk
group#/member# command.
Table 9-373. TEST #256 Service State Audit Test
Error
Code
Tes t
Result Description/ Recommendation
1000 ABORT Resources required to run this test were not available. The port may be on a
valid call or initializing. Use status station or status trunk to determine when
the trunk is available for testing. Check the results of Test #255.
1018 ABORT Maintenance is disable on this trunk.
1. Enable maintenance by entering ‘‘y’’ in the ‘‘Maintenance Tests?’’ field on
page 2 of the change trunk-group form.
1113 ABORT The signaling link has failed, so the system cannot send any messages on
behalf of this trunk.
1. Check the results of Test #255 and consult procedures for ‘‘ISDN-SGR
(ISDN-PRI Signaling Group)’’ in this chapter.
1114 ABORT The signaling link is in a transitional state.
1. Retry the command at 1-minute intervals for a maximum of 5 times.
1116 ABORT The trunk is not in the out-of-service/far-end state, which is required to run this
test on systems using a country protocol other than 1.
1117 ABORT A service state audit message is outstanding.
1. Wait 2 minutes and then try again.
2100 ABORT Could not allocate the necessary system resources to run this test.
1. Retry the command at 1-minute intervals for a maximum of 5 times.
1113 FAIL The signaling link has failed; the system cannot send any messages on behalf
of this trunk.
1. Consult procedures for ISDN-SGR (ISDN-PRI Signaling Group) and
ISDN-LNK (ISDN Signaling Link Port).
FAIL Internal system error
1. Retry the command at 1-minute intervals for a maximum of 5 times.
PASS Wait 4 minutes and then check the Error Log for any new errors of type 3073. If
there are none, then both sides of the ISDN connection agree on the service
state; the negotiation succeeded. If there is a new 3073 error, then the
negotiation failed (the far-end switch twice failed to respond within 2 minutes).
The switch will automatically retry every 15 minutes. If the trunk was initially
in-service, it is now placed in the maintenance/far-end state. Incoming calls will
be accepted, but no outgoing calls can be originated. If an incoming call is
presented, another Service State Audit will be immediately performed in an
attempt to put the DS1 ISDN Trunk in the proper state.
Continued on next page
