KEYS
CONFIGURATION DESCRIPTION
CPU
2
CPU
4
CPU
4 OSD
CPU
8 OSD
CPU
16 OSD
/
LINDY CPU Switch locks on to active ports only during autoscanning (default) Yes Yes Yes Yes Yes
/
LINDY CPU Switch locks on to every port during autoscanning Yes Yes Yes Yes Yes
/
LINDY CPU Switch powers on in autoscan mode & locks on to active ports only Yes Yes Yes Yes Yes
/
LINDY CPU Switch powers on in autoscan mode and locks on to all ports Yes Yes Yes Yes Yes
6
2 seconds of inactivity before allowing switchover between A & B ports (default) No No Yes Yes Yes
6
5 seconds of inactivity before allowing switchover between A & B ports No No Yes Yes Yes
6
10 seconds of inactivity before allowing switchover between A & B ports No No Yes Yes Yes
6
30 seconds of inactivity before allowing switchover between A & B ports No No Yes Yes Yes
6
1 minute of inactivity before allowing switchover between A & B ports No No Yes Yes Yes
6
5 minutes of inactivity before allowing switchover between A & B ports No No Yes Yes Yes
6
10 minutes of inactivity before allowing switchover between A & B ports No No Yes Yes Yes
7
2 seconds autoscan delay time before switching to next port (default) Yes Yes Yes Yes Yes
7
5 seconds autoscan delay time before switching to next port Yes Yes Yes Yes Yes
7
7 seconds autoscan delay time before switching to next port Yes Yes Yes Yes Yes
7
10 seconds autoscan delay time before switching to next port Yes Yes Yes Yes Yes
7
15 seconds autoscan delay time before switching to next port Yes Yes Yes Yes Yes
7
20 seconds autoscan delay time before switching to next port Yes Yes Yes Yes Yes
7
30 seconds autoscan delay time before switching to next port Yes Yes Yes Yes Yes
7
60 seconds autoscan delay time before switching to next port Yes Yes Yes Yes Yes
8
LINDY CPU Switch channels are switchable using a 3 button mouse or
IntelliMouse (default)(LINDY CPU Switch reports 2 button mouse mode to PCs)
Yes Yes Yes Yes Yes
8
LINDY CPU Switch channels are not switchable using 3 button mouse or
IntelliMouse (LINDY CPU Switch reports 2 button mouse mode to PCs)
Yes Yes Yes Yes Yes
8
LINDY CPU Switch channels are not switchable using 3 button mouse or
IntelliMouse (LINDY CPU Switch reports 3 button mouse mode to PCs)
Yes Yes Yes Yes Yes
8
LINDY CPU Switch channels are switchable using 3 button mouse or
IntelliMouse (LINDY CPU Switch reports IntelliMouse mode to PCs)
Yes Yes Yes Yes Yes
8
LINDY CPU Switch channels are not switchable using 3 button mouse or
IntelliMouse (LINDY CPU Switch reports IntelliMouse mode to PCs)
Yes Yes Yes Yes Yes
3
Sets password – see section 4.8 for instructions. Yes Yes Yes Yes Yes
(
Exits configure mode & returns the LINDY CPU Switch to normal operation
mode.
Yes Yes Yes Yes Yes
