4026-0XX
2-16
Cover Interlock Service Check
D-Roll Assembly Service Check
FRU Action
1
Right Hand
Transfer
Bracket
Check the right hand transfer bracket actuator
arm to be sure it contacts the interlock switch
actuator mounted in the LVPS.
Replace the bracket if the arm is damaged or
broken.
2
Top Cover
Interlock
Switch
If the interlock switch is being actuated correctly,
check the continuity of the switch between
CN7A-1andCN7A-2onthecableasyouacti-
vate the switch. If incorrect, replace the LVPS.
3
LVPS Be sure the voltage at CN7-1 measures +24 V
dc. If incorrect, turn the printer power off and
disconnect the LVPS cable from the engine
board. Turn the printer power on. The voltage on
the LVPS cable pin 1 should measure approxi-
mately+24Vdc.Ifincorrect,replacetheLVPS.
If correct, go to the “Low Voltage Power Supply
Service Check” on page 2-22.
FRU Action
1
D-Roll Check the D-roll for wear, broken, or worn parts.
Replace as necessary.
2
D-Roll Clutch
Assembly
Be sure the clutch assembly operates correctly.
Replace as necessary.
3
Solenoid Be sure the paper feed solenoid operates cor-
rectly. If the solenoid fails to pick, go to the
“Paper Take-Up Solenoid Service Check” on
page 2-32.
4
Paper Feed
Drive Gears
Be sure the main drive/paper feed gears operate
correctly. Check for broken teeth or damaged
gears. Replace as necessary.
