Using the appliance safely:
• In the event of danger, immediately
remove the power plug from the wall
socket.
• Never use the appliance for purposes
other than those for which it was
designed.
• Remove the power plug from the wall
socket when the appliance is not in
use, when you remove parts and
before cleaning the appliance.
• Do not use the appliance outdoors.
Appliance description
q Lid
w Large squeezing cone
e Small squeezing cone
r Upper fruit pulp sieve
t Fruit pulp regulator
y Lower fruit pulp sieve
u Juice collector
i Drive axle
o Power cable with power plug
a Appliance plinth
s Power cable storage
Set-up and assembly of the appliance
ƽ Important: Ensure that the power
plug is not in the power socket before
assembling the appliance.
1. Unwind the power cable
o completely
from the cable storage
s and secure
it in the lateral recess on the appliance
plinth
a.
2. Place the appliance plinth
a on a level
and slip-free surface.
Note: Rinse all removable compo-
nents thoroughly before the first
usage of the appliance (see chapter
"Cleaning and care").
3. Place the juice collector
u on the drive
axle
iof the appliance plinth a and
turn it clockwise as far as it will go.
4. Place both parts of the fruit pulp sieve
r/y into each other so that the fruit
pulp regulator
tprotrudes through
the recess. Both parts must audibly
engage.
5. Place the assembled fruit pulp sieve
r/y on the juice collector u. The fruit
pulp regulator
t must lie on the grip
and catch in the rabbet on the grip.
6. Press the small squeezing cone
eon
the drive axle
i so that it engages.
Note: If you want to press oranges
or other larger fruits, place the large
squeezing cone
w over the small
squeezing cone
e. Ensure that the
lobes of the small squeezing cone
e
engage in the recesses of the large
squeezing cone
w.
7. Insert the power plug into a wall
power socket. The appliance is now
ready for use.
