29
2. CONTROLS, INDICATORS AND CONNECTORS
OFF ZONE 1 ZONE 3ZONE 2
--- - - CAMERA MENU -
SCENE FI LE : A
VF DISPLAY MENU
OPERATI ON MENU
PROCESS MENU
F ILE MANAGE
SETUP MENU
EXIT
AUTO WH AITE
OPERATION
SHUTTER 1/1000
Ⅲ Safety Zone
Three types of safety zone items can be displayed in the viewfinder. Select the required one with the SAFETY ZONE item on the
VF DISPLAY menu screen.
Ⅲ Setting the Screen Display
Ⅲ Auto White Balance Display
Ⅲ Shutter Speed Display
Screen used for making various settings of the camera and VCR.
☞ See "Camera Menu Screen Flow" on page 70.
☞ See "VCR Setup Menu" on page 66.
This screen appears during the auto white balance adjustment operation to display various
data.
☞ See "White Balance Adjustment" on page 45.
When the SHUTTER dial is pressed, a shutter speed is displayed (for approx. 5 sec.).
In addition, whenever the shutter speed is altered by using the SHUTTER dial, the shutter
speed is displayed. While this display is shown, other displays disappear.
☞ See "SHUTTER/MENU dial" on page 12.
2-9 Indications in Viewfinder (Cont'd)
30
3. BASIC SYSTEM CONNECTIONS AND ADJUSTMENTS
For information on connection with the individual attachments, refer to the page explaining the respective connection methods.
3-1 Basic System
VC-710
(
5m
)
(
NB-G1 BATTERY CHARGER
)
AC POWER ADAPTER
AA-P250
EARPHONE
VIDEO LIGHT
(ANTON BAUER. PROTEC)
SHOULDER BELT
VIEWFINDER
VF-P400
VF HOLDER
TP-P300
TP-P205
DOLLY
TRIPOD BASE
KA-510
NB-G1
(
4PACK
)
BATTERY CHARGER
(AC POWER ADAPTER)
AA-G10(B)
BATTERY
NP-1B TYPE
BATTERY
NP-1B TYPE
BATTERY CHARGER
BATTERY
NB-G1
BATTERY HOLDER
BH-P27
MIC HOLDER
KA-A50
MICROPHONE
MV-P615
MICROPHONE
DVC CAMCORDER
CARRYING CASE
FOCUS MANUAL UNIT
HZ-FM13
(
FUJINON
)
HZ-FM15
(
CANON
)
ZOOM SERVO UNIT
HZ-ZS13B
ZOOM LENS
S14 x 7.3B12(FUJINON)
S16 x 6.7B12(FUJINON)
S19 x 6.5B12(FUJINON)
YH14 x 7.3K12(CANON)
YH18 x 6.7K12(CANON)
TRIPOD
1.5" VIEW FINDER
VF-P115B/115/116
TRIMPAC
,
HYTRON
)
ANTON BAUER
BATTERY HOLDER
(QRQ27)
(
PRO PAC
,
MAGNUM
,
ANTON BAUER BATTERY
IEEE1394 CABLE
RS232C CABLE
VC-P893 (For PC/AT)
Y/C CABLE
VCG30, VCG50
ANTON BAUER
BATTERY CHARGER
4P4P
AC
3P
GY-DV500
STANDARD
PACKAGE
MACRO
LIGHT
ON
OFF
COUNTER
CTL
TC
UB
RESET
OPERATE/WARNING
MONITOR
SELECT
STATUSSHUTTER
MENU
FILTER
1 3200k
2 5600k
3 5600k+ND
POWER
NG
G
A
I
N
O
U
T
P
U
T
W
H
T
.B
A
L
V
T
R
ON OFF
ALARM
MONITOR
S
A
V
E
S
T
B
Y
H
M
L
B
A
R
S
C
A
M
A
UTO
K
N
E
E
P
R
S
T
A
B
O
N
OF
F
CH-1
CH-2
AUDIO
LEVEL
AUTO IRIS LOLUX
BACK L
NORMAL
SPOT L
STRETCH
NORMAL
COMPRESS
FULL AUTO BLACK
BNC CABLE
* HZ-FM13 cannot be used with S14X7.3B12/U.
Please use the Focus Manual Unit (FMM-8, CHF-3, CFC-12-990) manufactured by Fujinon.
For servicing
See the service manual page 1-16 “1.11.7 Tripod base”.
→
