Remote Control
Infrared Beam Transmitting Window
ZOOM (T/W) Buttons (Zoom in/Out)
Up Button
Skip Backward Button
Left Button
Back Button
PLAYLIST Button
START/STOP Button
S.SHOT (SNAPSHOT) Button
INFO Button
Skip Forward Button
PLAY/PAUSE/SET Button
Right Button
Next Button
Down Button
INDEX Button*
DISP Button
Camcorder
Power Button
HDMI Mini Connector (੬ p. 31)
DISPLAY Button (੬ p. 15)
Speaker
Zoom Lever (੬ p. 22)
Speaker Volume Control
SNAPSHOT Button (੬ p. 21)
Touch Sensor
OK Button
MENU Button
Mode Switch [
, ]
UPLOAD Button (੬ p. 57)
TITLE Button (੬ p. 41)
EXPORT Button (੬ p. 55)
DIRECT DVD Button (੬ p. 45)
INFO Button (੬ p. 22, 23, 37)
PLAY/REC Button (੬ p. 20, 21, 24, 25)
LED Light (੬ p. 22)
Remote Sensor
Lens
Stereo Microphone
DC Connector
START/STOP Button (੬ p. 20)
AV Connector (੬ p. 31, 53, 54)
USB Connector (੬ p. 44, 49)
Everio Dock Connector
Tripod Mounting Socket
microSD Card Slot
Battery Release Button
* Each time you press INDEX, the screen
switches as shown below:
mode:
Index Screen Group Index Screen
mode:
Index Screen Date Index Screen
