EN 47
SPECIFICATIONS
GENERAL
Format : VHS PAL standard
Power source : DC 6 V
Power consumption
LCD monitor off,
viewfinder on : 6.3 W
LCD monitor on,
viewfinder off : 6.7 W
Light : 3 W
Signal system : PAL-type
Video recording system
Luminance : FM recording
Colour : Converted sub-carrier
direct recording
Conforms to VHS
standard
Cassette : cassette
Tape speed
SP : 23.39 mm/sec
LP : 11.70 mm/sec
Recording time Max.
SP : 60 minutes
(with EC-60 cassette)
LP : 120 minutes
(with EC-60 cassette)
Operating temperature : 0°C to +40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to +50°C
Weight : Approx. 1,040 g
Dimensions : 118 (W) x 115 (H) x
231 (D) mm
CAMERA
Pick up : 1/4” format CCD
Lens : F1.6, f = 3.8 to 68.4 mm,
18:1 power zoom lens
with auto iris and macro
control, filter diameter
46 mm
Viewfinder : Electronic viewfinder
with 0.5” B/W CRT
White balance
adjustment : Auto/Manual adjustment
LCD MONITOR
Size : 3" diagonally measured
LCD system : LCD/TFT active matrix
system
VIDEO
Output : 1 Vp-p, 75 ohms,
unbalanced (via VIDEO
out connector)
AUDIO
Output : –8 dBs, 1 k-ohm
(via AUDIO out
connector)
Speaker : 20 mm round x 1,
monaural
AC POWER ADAPTER/BATTERY CHARGER
(AA-V11EG/EK)
Power requirement : AC 110 to 240 V`,
50/60 Hz
Power consumption : 23 W
Output : DC 8.5 V , 1.3 A
(CHARGE),
DC 6.3 V , 1.8 A
(VTR)
Charging system : Constant current, peak
detection, timer
controlled
Dimensions : 150 (W) x 42 (H) x
68 (D) mm
Weight AA-V11EG : Approx. 350 g
AA-V11EK : Approx. 400 g
CASSETTE ADAPTER (C-P7U)
Dimensions : 188 (W) x 25 (H) x
104 (D) mm
Weight : Approx. 240 g
Accessory : “R6 (AA)”-size battery x 1
Provided Accessories ......................੬ pg. 3
Optional Accessories
•Battery Packs BN-V12U, BN-V22U, BN-V25U
•Car Battery Charger BH-V3E
•RF Unit RF-V5E
•Compact VHS-C Cassettes EC-60/45/30
•Active Carrying Bag CB-V7U
•Wireless Remote Control Unit RM-V704U or
RM-V700U
Some acccessories are not available in some areas.
Please consult your nearest JVC dealer for details on
accessories and their availability.
Specifications shown are for SP mode unless
otherwise indicated. E.&O.E.Design and specifica-
tions subject to change without notice.
