Specifications:
Enclosure Type: Sealed
Driver Type: 12W3v2-D2
Nominal Impedance: 4Ω
Cont. Power Handling: 300 Watts
JL Audio recommends using a high quality amplifier such as the JL Audio 250/1. The diagram below shows the recommended
crossover, infrasonic filter and equalizer settings for the 250/1 when being used to power your Stealthbox®.
Included Hardware:
(2) 3/8-16 x 2-1/4” Socket Cup Set Screws
(2) 3/8” x 1-1/4” Fender Washer
(2) 3/8” Flat Washer
(2) 3/8” Split Lock Washer
(2) 3” x 3” Wax Squares
10369 N. Commerce Pkwy, Miramar, Florida 33025-392 Phone: 954.443.1100 Fax: 954.443.1111
Input Sens.
Left Ch.
Right Ch.
Left Ch.
Right Ch.
Filter Freq. (Hz)
The JL Audio 250/1 is a very versatile audio component. Please consult the owner’s manual for detailed information
about installing and tuning this amplifier.
➔
STEP 14: Back out the pair of socket cap set
screws that were threaded in, from STEP 8. Expose
1-1/2” of the threads, outside the Stealthbox.
Place the Stealthbox into location, carefully guiding
the pair of socket cup set screws through the drilled
holes.
Using the supplied hardware, place in order as
shown n above illustration.
➔
SB-H-CIVCPE2/12W3v2, JL AUDIO, Inc 2004
Sheet SKU#011158 Revision 9/17/2004Page 3
www.jlaudio.com
Mid/High Frequency Driver Information:
CONGRATULATIONS!
INSTALL COMPLETE.
