7K200 SATA OEM Specification
18/173
4.2 Data sheet
200GB 160GB 120GB 100GB 80GB
Rotational Speed (RPM) 7200 7200 7200 7200 7200
Data transfer rates (buffer to/from
media) (Mbps)
876 695 695 876 695
Data transfer rates (Gbit/sec) 1.5/3.0 1.5/3.0 1.5/3.0 1.5/3.0 1.5/3.0
Recording density (Kbit/mm) (Max)
(KBPI) (Max)
994
903
903
994
903
Track density (Ktrack/mm)(Max)
(KTPI)(Max)
164
146
146
164
146
Areal density (Gbit/sq-mm.- Max)
(Gbit/sq-inch - Max)
164
132
132
164
132
Number of zones 24 24 24 24 24
Table 2. Data sheet
4.3 Cylinder allocation
Data format is allocated by each head characteristics. Typical format is described below.
80GB/p Mid BIP-Mid TPI format
Zone
Cylinder
No. of
Sectors/Trk
0 0 - 5279 1209
1 5280 - 10559 1209
2 10560 - 13759 1196
3 13760 - 18559 1170
4 18560 - 23359 1144
5 23360 - 26559 1131
6 26560 - 28959 1118
7 28960 - 34239 1092
8 34240 - 39039 1053
9 39040 - 43839 1040
10 43840 - 48639 1014
11 48640 - 53439 975
12 53440 - 55839 962
13 55840 - 61279 939
14 61280 - 65279 910
15 65280 - 69119 884
16 69120 - 72479 858
17 72480 - 78559 819
18 78560 - 80159 806
19 80160 - 85279 780
20 85280 - 88959 741
21 88960 - 92959 702
22 92960 - 96799 663
23 96800 - 102399 624
Table 3. Cylinder allocation
