QuickSpecs
hp StorageWorks
modular SAN array 1000
specific for Tru64 UNIX and OpenVMS only
DA-11621 Canada — Version 2 — April 15, 2003 13
Configuration Information
STEP 5 – CHOOSE HARD DRIVES & STORAGEWORKS ENCLOSURES (continued)
StorageWorks Enclosures
The msa1000 cabinet holds fourteen 1” Universal Drives. Add one StorageWorks
Enclosure to increase capacity up to 28 drives. Add two HP StorageWorks Enclosures
to increase capacity up to the maximum of 42 drives.
HP StorageWorks Enclosure Model 4314R (Maximum of two can be connected to the
msa1000)
190209-001
HP StorageWorks Enclosure Model 4354R (Maximum of one can be connected to the
msa1000)
190211-001
STEP 6 – CHOOSE RACK OPTIONS
9142 Rack
120663-B21, -B22, -B23
9136 Rack
120664-B21, -B22, -B23
9122 Rack
120665-B21, -B22, -B23
9842 Rack
222192-B21
10647 (47U) rack
245160-B21, -B23
10642 (42U) rack
245161-B21, -B22, -B23
10636 (36U) rack
245162-B21, -B22, -B23
10622 (22U) rack
245163-B21, -B22, -B23
H9A10 Cab
H9A10-XX
H9A15 Cab
H9A15-XX
