QuickSpecs
HP Compaq nx6310 Notebook PC
Technical Specifications
DA – 12432 EMEA — Version 10 — June 27, 2006 Page 14
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 150 nit (typical)
Pitch 0.296 mm
Format 1024 x 768
Pixel Resolution
Configuration RGB Stripe
Backlight CCFL
PPI 86
Viewing Angle ±45° Horizontal, ±25° Vertical (typical)
Active Area (W x H) 12.0 x 9.0 in (30.4 x 22.8 cm)
Diagonal Size 15.0 in (38.0 cm)
Surface Treatment BrightView
Number of Colors Up to 16M
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 150 nit (typical)
Pitch 0.296 mm
Format 1024 x 768
Pixel Resolution
Configuration RGB Stripe
Backlight CCFL
PPI 86
15.0-Inch Color TFT
XGA BrightView Display
Viewing Angle ±45° Horizontal, ±25° Vertical (typical)
Hard Drives
Drive Weight 0.22 lb (101 g)
Capacity 100 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7 / SATA 1.0a
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Single Track 3 ms
Average 13 ms
Seek Time
(typical reads, including
settling)
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 195,371,568
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
100-GB 5400 rpm SATA
Features ATA Security
Drive Weight 0.22 lb (101 g)
Capacity 80 GB
80-GB 5400 rpm SATA
Height 0.37 in (9.5 mm)
