Illustrated parts catalog
Maintenance and Service Guide 3–5
Switzerland 518965-111
Taiwan 518965-AB1
Thailand 518965-281
Turkey 518965-141
The United Kingdom 518965-031
The United States 518965-001
Keyboard, Espresso Black, textured keyboard characters (includes keyboard cable) for
use in the United States
518966-001
(5) Speaker assembly (includes left and right speakers and cable)
For use in all countries and regions except India 533865-001
For use only in India 571902-001
(6) Top cover (includes speakers, TouchPad and cable, LED board and cable, and switch cover)
For use only with white computer models not equipped with a fingerprint reader 518108-001
For use only with black computer models not equipped with a fingerprint reader 518788-001
For use only with black computer models equipped with a fingerprint reader 579160-001
(7) System board (includes replacement thermal material)
With discrete graphics subsystem and 1-GB of dedicated memory 574902-001
(8) Power connector cable 533465-001
Cable Kit (see
“Cable Kit” on page 3-12 for more Cable Kit spare part information) 512832-001
(9a) Modem module cable
✎
The modem module cable includes the RJ-11 jack
(9b) TV tuner cable
Plastics Kit (see “Plastics Kit” on page 3-11 for more Plastics Kit spare part information) 579162-001
(10a) ExpressCard port bezel
(10b) Memory module compartment cover
(10c) Hard drive port bezel cover
(11) Processor (includes replacement thermal material)
Intel CoreT i7-820-QM processor 1.73 GHz, SC turbo up to 3.06 GHz 583053-001
Intel CoreT i7-720-QM processor 1.6 GHz, SC turbo up to 2.8 GHz 586170-001
(12) Fan/heat sink assembly (includes replacement thermal material)
For use only with computer models equipped with graphics subsystems with discrete
memory
579158-001
(13) Base enclosure (includes rubber feet) 579157-001
Rubber Feet Kit (not illustrated, includes 4 base enclosure rubber feet) 516499-001
(14) Audio/infrared board (includes cable)
For use in computers with discrete graphics subsystems 512836-001
(15) USB board (includes cable)
For use in computers with discrete graphics subsystems 516855-001
(16) Battery
12-cell, 95-Wh, 8.8-Ah Li-ion battery 511884-001
Item Description Spare Part Number
