5–4 Maintenance and Service Guide
Removal and Replacement Procedures
Section Description
# of Screws Removed
5.9 Optical Drive 1 to remove the optical drive
2 to remove the optical drive
bracket
5.10 Keyboard 3
5.11 Switch Cover 4 to remove the switch cover
2 to remove the power switch
board
5.12 Display Assembly
Display bezel
Web camera
Display inverter
Display hinges
Display panel
Wireless antenna transceivers
Microphones
Web camera cable
5
6
3
2
4
0
2
0
0
5.13 Top Cover 18
5.14 TouchPad 7
5.15 Wireless Switch Board 2
5.16 Modem Module 2
5.17 Audio/Infrared Board 2
5.18 Bluetooth Module 2
5.19 USB Board 1
5.20 Speaker Assembly 3
5.21 Display Lid Switch Module 2 to remove top cover rear
strip
1 to remove the display lid
switch module
5.22 System Board 2
Disassembly Sequence Chart
(Continued)
