Memory
Embedded Slots
1 2 3 4 5 6 7 8
1A
2C
3E
4G
5A
6C
7E
8G
Standard
4 GB
1 GB
Empty Empty Empty
1 GB
Empty Empty Empty
Standard +
Optional
Maximum:
228GB
Shown:
60 GB
1 GB 2 GB 2 GB 2 GB 1 GB 2 GB 2 GB 2 GB
Maximum
256 GB
8 GB 8 GB 8 GB 8 GB 8 GB 8 GB 8 GB 8 GB
Memory
Embedded Slots
9 10 11 12 13 14 15 16
9B
10D
11F
12H
13B
14D
15F
61H
Standard
4 GB
1 GB
Empty Empty Empty
1 GB
Empty Empty Empty
Standard +
Optional
Maximum:
228 GB
Shown:
60 GB
1 GB 2 GB 2 GB 2 GB 1 GB 2 GB 2 GB 2 GB
Maximum
256 GB
8 GB 8 GB 8 GB 8 GB 8 GB 8 GB 8 GB 8 GB
Expansion Board
Memory
Optional DL580 G5 Memory Expansion Boards Option Slots
17 18 19 20 21 22 23 24
1A 2B
3C 4D
1A 2B
3C 4D
Standard
4 GB
Empty Empty Empty Empty Empty Empty Empty Empty
Standard +
Optional
Maximum:
228 GB
Shown:
60 GB
2 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB
Maximum
256 GB
4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB
Expansion Board
Memory
Optional DL580 G5 Memory Expansion Boards Option Slots
25 26 27 28 29 30 31 32
1A 2B
3C 4D
1A 2B
3C 4D
Standard
4 GB
Empty Empty Empty Empty Empty Empty Empty Empty
Standard +
Optional
Maximum:
228 GB
Shown:
60 GB
2 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB
Maximum
256 GB
4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB
NOTE:
Memory channel 1 includes slots 1-4 (on board) and 17-21 (expansion board #1)
Memory channel 2 includes slots 5-8 (on board) and 21-24 (expansion board #2)
Memory channel 3 includes slots 9-12 (on board) and 25-28 (expansion board #3)
Memory channel 4 includes slots 13-16 (on board) and 29-32 (expansion board #4)
QuickSpecs
HP ProLiant DL580 Generation 5
Memory
DA - 12770 Worldwide QuickSpecs — Version 18 — 7.18.2008
Page 36
