Rack Airflow
Rack AirflowRack Airflow
Rack Airflow
Requirements
RequirementsRequirements
Requirements
Rack 10000 series Cabinets
Rack 10000 series CabinetsRack 10000 series Cabinets
Rack 10000 series Cabinets
The increasing power of new high-performance processor technology requires increased cooling
efficiency for rack-mounted servers. The 10000 Series Racks provide enhanced airflow for maximum
cooling, allowing these racks to be fully loaded with servers using the latest processors.
CAUTION:
CAUTION: CAUTION:
CAUTION:
If a third-party rack is used, observe the following additional requirements to ensure
adequate airflow and to prevent damage to the equipment:
Front and rear doors
:
If your 42U server rack includes closing front and rear doors, you must
allow 830 square inches (5,350 sq cm) of hole evenly distributed from top to bottom to permit
adequate airflow (equivalent to the required 64 percent open area for ventilation).
Side:
The clearance between the installed rack component and the side panels of the rack must be
a minimum of 2.75 inches (7 cm).
CAUTION:
CAUTION: CAUTION:
CAUTION:
Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This
arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling
that can lead to thermal damage.
NOTE:
NOTE: NOTE:
NOTE:
For additional information, refer to the Setup and Installation Guide or the Documentation CD
provided with the server, or to the server documentation located in the Support section at the following
URL:
http://h18000.www1.hp.com/products/servers/proliantdl360/index.html
.
Factory Express Portfolio
Factory Express PortfolioFactory Express Portfolio
Factory Express Portfolio
for Servers and Storage
for Servers and Storagefor Servers and Storage
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to
http://www.hp.com/go/factory-express
.
Customer Builder
Customer BuilderCustomer Builder
Customer Builder
Please see the Enterprise Configurator for configuration assistance at:
http://www.hp.com/products/configurator
.
QuickSpecs
HP ProLiant DL360 Generation 4p (G4p)
HP ProLiant DL360 Generation 4p (G4p)HP ProLiant DL360 Generation 4p (G4p)
HP ProLiant DL360 Generation 4p (G4p)
Standard Features
DA - 12166 North America — Version 24 — August 15, 2006
Page 9
