Buttons on the Home screen
The Home screen provides access to the product features, and it indicates the product status.
NOTE: Depending on the product configuration, the features on the Home screen can vary. The layout
might also be reversed for some languages.
1
10 9 8
2 3 4
5
6
7
1 Setup button: provides access to the main menus
2
Network button: provides access to network settings and information. From the network settings screen,
you can print the Network Summary page.
3 Wireless button: provides access to the Wireless menu and wireless status information.
NOTE: Wireless models only
NOTE: When you are connected to a wireless network, this icon changes to a set of signal strength bars.
4 Information button: provides product status information. From the status summary screen, you can print the
Configuration Report page.
5 Supplies button: provides information about supplies status. From the supplies summary screen, you can print
the Supplies Status page.
6 Product status
7 USB button: provides access to the USB flash drive options.
8 Scan button: provides access to the scan feature
9 Fax button: provides access to the fax feature
10 Copy button: provides access to the copy feature
