Spare part number Description
628668-001 6-cell, 62-Wh, 2.80-Ah, Li-ion battery
628670-001 6-cell, 55-Wh, 2.80-Ah, Li-ion battery
628824-001 Modem module (does not include the modem module cable)
NOTE: The modem module cable is included in the Cable Kit, spare part number 641830-001.
631243-001 9-cell, 100-Wh, 3.0-Ah, Li-ion battery
633252-001 750-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket or screws)
NOTE: The hard drive bracket and screws are included in the Hard Drive Hardware Kit, spare
part number 642774-001.
634087-001 9-cell, 100-Wh, 3.00-Ah, Li-ion battery
634089-001 6-cell, 73-Wh, 2.20-Ah, Li-ion battery
634862-001 320-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket or screws)
NOTE: The hard drive bracket and screws are included in the Hard Drive Hardware Kit, spare
part number 642774-001.
634925-001 500-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket or screws)
NOTE: The hard drive bracket and screws are included in the Hard Drive Hardware Kit, spare
part number 642774-001.
641369-001 4-GB memory module (PC3, 12800, 1600-MHz)
641830-001 Cable Kit (includes Bluetooth module cable, RJ-11 jack cable, and TouchPad cable)
641831-001 Rubber Kit (includes display bezel left and right rubber screw covers, base enclosure front and rear
rubber screw covers, top cover rubber bumper)
641836-001 Display Hinge Kit (includes left and right display hinges and left and right hinge brackets)
641839-001 Fan (includes cable)
641840-001 Speaker assembly (includes cable)
642774-001 Hard Drive Hardware Kit (includes hard drive bracket and screws)
642778-001 Display enclosure
642783-001 Display Hinge Cover Kit (includes left and right display hinge covers)
642785-001 Display Rubber Kit (includes display bezel rubber screw covers and display bezel rubber bumpers)
642797-001 Microphone module
642799-001 WLAN Antenna Kit (includes left and right WLAN antenna cables and transceivers)
642801-001 WWAN Antenna Kit (includes left and right WWAN antenna cables and transceivers)
651948-001 RTC battery (includes cable and double-sided tape)
652972-001 2-GB memory module (PC3, 12800, 1600-MHz)
655792-001 Bluetooth module 4.0 EDR (does not include the Bluetooth module cable)
NOTE: The Bluetooth module cable is included in the Cable Kit, spare part number 641830-001.
48 Chapter 3 Illustrated parts catalog
