Display assembly
Description Spare part number
Display assemblies for use with computer models equipped with WLAN and WWAN capability (includes 3 WLAN antenna
transceivers and cables and 2 WWAN antenna transceivers and cables)
15.4-in, WXGA
495043-001
15.4-in, WSXGA+ 495044-001
15.4-in, WUXGA 495045-001
Display assemblies for use with HP EliteBook 8530w computer models equipped with WLAN and WWAN capability (includes
3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
15.4-in, WXGA
495046-001
15.4-in, WSXGA+ 495047-001
15.4-in, WUXGA 495048-001
Display assemblies for use with computer models equipped WLAN and WWAN capability and integrated webcam (includes 3
WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
15.4-in, WXGA
495049-001
15.4-in, WSXGA+ 495050-001
15.4-in, WUXGA 495051-001
Display assemblies for use with HP EliteBook 8530w computer models equipped with WLAN and WWAN capability and
integrated webcam (includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
15.4-in, WXGA
506809-001
15.4-in, WSXGA+ 506810-001
15.4-in, WUXGA 506811-001
Display assemblies for use with HP EliteBook 8530w computer models equipped with Intel Core2 Extreme and Quad
processors, and WLAN and WWAN capability (includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna
transceivers and cables)
15.4-in, WXGA
515889-001
15.4-in, WSXGA+ 515890-001
15.4-in, WUXGA 515891-001
Display assemblies for use with HP EliteBook 8530w computer models equipped with Intel Core2 Extreme and Quad
processors, WLAN and WWAN capability (includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna
transceivers and cables)
15.4-in, WXGA with integrated webcam
515892-001
15.4-in, WSXGA+ with integrated webcam 515893-001
15.4-in, WUXGA with integrated webcam 515894-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
