Personal Area Networking Profile (PAN)*
Human Interface Device Profile (HID)*
FAX Profile (FAX)
Basic Imaging Profile (BIP)
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
* indicates the profile is also supported by Microsoft Windows XP SP2
Eco Data
Eco-Label
Certifications
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
US Energy Star
Taiwan Green Mark
IT ECO declaration
EPEAT – SILVER
System Configuration
The configuration used for the Energy Consumption and Declared
Noise Emissions data for the Convertible Mini tower Desktop model is
based on a "Typically Configured Notebook"
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
13.44 W 13.55 W 13.20 W
Sleep (Energy Star low
power mode)
1.61 W 1.61 W 1.58 W
Off
0.511 W 0.541 W 0.512 W
Heat Dissipation*
115 VAC 230 VAC 100 VAC
Normal Operation
46 BTU/hr 46 BTU/hr 45 BTU/hr
Sleep
6 BTU/hr 6 BTU/hr 5 BTU/hr
Off
2 BTU/hr 2 BTU/hr 2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming
the service level is attained for one hour.
This product is in compliance with US executive order 13221, WOL
(wake on LAN) disabled.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
System Fan Off
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle
4.4
27
Fixed Disk
(random writes)
4.4
28
System fan is usually off except when charging the battery
Batteries
This product complies with ISO standards:
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
QuickSpecs
HP Compaq 6535b Notebook PC
Technical Specifications
DA - 13054 Worldwide QuickSpecs — Version 11 — 12/5/2008
Page 32
