Microsoft Windows Vista Wireless Network Connection Manager
Broadcom IHV extensions for Windows Vista available to support
Cisco Compatible Extensions.
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN
supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows
Vista.
HP Integrated Module
HP Integrated ModuleHP Integrated Module
HP Integrated Module
with Bluetooth 2.1
with Bluetooth 2.1with Bluetooth 2.1
with Bluetooth 2.1
Wireless Technology
Wireless TechnologyWireless Technology
Wireless Technology
Bluetooth Specification
Bluetooth SpecificationBluetooth Specification
Bluetooth Specification
2.1 Compliant
Dimensions
DimensionsDimensions
Dimensions
1.18 x 0.26 x 0.13 in (30 x 6.5 x 3.25 mm)
Frequency Band
Frequency BandFrequency Band
Frequency Band
2402 to 2480 MHz
Number of Available
Number of AvailableNumber of Available
Number of Available
Channels
ChannelsChannels
Channels
79 (1 MHz) available channels
Data Rates and
Data Rates andData Rates and
Data Rates and
Throughput
ThroughputThroughput
Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or
1306.9 kbps symmetric
Transmit Power
Transmit PowerTransmit Power
Transmit Power
-6 dBm to 4 dBm (Bluetooth Class II)
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity
Better than -80 dBM at 0.1 % raw bit error rate
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
Peak (Tx) 264 mW
Peak (Rx) 231 mW
Sleep <1 mW
Antenna
AntennaAntenna
Antenna
Internally integrated within module
Range
RangeRange
Range
Up 33 ft (10 m)
Electrical Interface
Electrical InterfaceElectrical Interface
Electrical Interface
USB 2.0 compliant
Microsoft Windows Plug and Play compliant
Bluetooth Software
Bluetooth SoftwareBluetooth Software
Bluetooth Software
Supported
SupportedSupported
Supported
Broadcom Bluetooth for
Microsoft Windows Bluetooth Software
Link Topology
Link TopologyLink Topology
Link Topology
Point to Point, Multipoint Pico Nets up to 7 slaves
Security
SecuritySecurity
Security
Full support of Bluetooth Security Provisions
Power Management
Power ManagementPower Management
Power Management
Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,
including Standby, Hold, Park, and Sniff
Certifications
CertificationsCertifications
Certifications
All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
QuickSpecs
HP ProBook 5310m Notebook PC
HP ProBook 5310m Notebook PCHP ProBook 5310m Notebook PC
HP ProBook 5310m Notebook PC
Technical Specifications
DA - 13394 Worldwide — Version 2 — December 2, 2009
Page 25
