Keyboard
KeyboardKeyboard
Keyboard
The HP spill-resistant keyboard is designed using a Mylar film that minimizes the risk of damage to
sensitive components underneath. The 101/102-key compatible keyboard features an industry standard,
full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys,
editing keys, both left and right control and alt keys, and 12 function keys. US and International key
layouts are available. Other features include a full numeric keypad, hotkeys for instant access to power
conservation, brightness, and other features, 19.05 x 19.05 mm key pitch (center-to-center spacing), 3.0
mm stroke, and comfort-dished keycaps.
Pointing device
Pointing devicePointing device
Pointing device
Touchpad with scroll zone, two pick buttons
Expansion card slots
Expansion card slotsExpansion card slots
Expansion card slots
ExpressCard/34 slot
ExpressCard/34 slotExpressCard/34 slot
ExpressCard/34 slot
Supports ExpressCard/34 (34 mm x 75 mm x 5 mm) card sizes
Media Card Reader
Media Card ReaderMedia Card Reader
Media Card Reader
Supports SD (Secure Digital), MMC (MultiMedia Card), Memory Stick,
Memory Stick Pro, Memory Stick Duo
*
, xD-Picture card
* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo Card
directly into your notebook could damage the memory card and/or notebook.
Storage
StorageStorage
Storage
Internal Storage Device
Internal Storage DeviceInternal Storage Device
Internal Storage Device
160/250/320/500 GB 5400 rpm SMART SATA II Hard Drive
NOTE:
NOTE:NOTE:
NOTE:
Up to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard
HP 3D DriveGuardHP 3D DriveGuard
HP 3D DriveGuard
(Windows models only)
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Fixed optical drives
Fixed optical drivesFixed optical drives
Fixed optical drives
Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive
*
DVD+/-RW SuperMulti DL LightScribe Drive
*Models with integrated graphics require Mobile Intel GM45 Express chipset
and Windows Vista to support the Blu-ray DVD drive; models with discrete
graphics support it with either Windows Vista or Windows XP.
Interfaces
InterfacesInterfaces
Interfaces
External monitor
External monitorExternal monitor
External monitor
One (VGA)
HDMI
HDMIHDMI
HDMI
One – 1.3 compliant
Stereo microphone in
Stereo microphone inStereo microphone in
Stereo microphone in
One
Stereo headphone/line
Stereo headphone/lineStereo headphone/line
Stereo headphone/line
out
outout
out
One
Power connector
Power connectorPower connector
Power connector
One
RJ-11/modem (optional)
RJ-11/modem (optional)RJ-11/modem (optional)
RJ-11/modem (optional)
One
RJ-45/Ethernet
RJ-45/EthernetRJ-45/Ethernet
RJ-45/Ethernet
One
USB 2.0
USB 2.0USB 2.0
USB 2.0
Four
LED status indicators
LED status indicatorsLED status indicators
LED status indicators
Seven
QuickSpecs
HP ProBook 4510s Notebook PC
HP ProBook 4510s Notebook PCHP ProBook 4510s Notebook PC
HP ProBook 4510s Notebook PC
Standard Features
DA - 13253 North America — Version 4 — May 15, 2009
Page 7
