6. Check, in the Port Members field, the checkboxes of the ports that you want to include.
NOTE: Check the checkbox of a particular card to automatically check all ports on that card.
7. Click the radio button of the distribution type to apply to the trunk group in the Distribution Type
field.
8. Click the Apply button.
Viewing Trunk Group Properties
To view the properties of a trunk group:
1. Expand the Ethernet icon in the Tree frame.
2. Click the Trunk Groups branch. The Trunk Groups table appears in the View frame.
3. Click the radio button next to the trunk group whose properties you want to view, then click the
Properties button. The Ethernet Trunk Group Properties window opens. Table 6-7 lists and
describes the elements in this window.
Table 6-7: Ethernet Trunk Group Properties Window Elements
Element Description
ID field ID number of the trunk group.
Name field Name of the trunk group.
Port Members field Ports that belong to the trunk group.
Distribution Type field Distribution type of the trunk group. This field displays one of the
following types:
• srcMac—bases load distribution on the source MAC address
of the incoming packet. Packets from different hosts use
different ports in the channel, but packets from the same host
use the same port in the channel.
• dstMac—bases the load distribution on the destination host
MAC address of the incoming packet. Packets to the same
destination travel on the same port, but packets to different
destinations travel on different ports in the channel.
• srcDstMac—bases load distribution on the MAC address of
the source logic gate (XOR) destination.
• srcIp—bases the load distribution on the source IP address.
Packets from the same source travel on the same port, but
packets from different sources travel on different ports in the
channel.
• dstIp—bases the load distribution on the destination IP
address of the incoming packet. Packets to the same
destination travel on the same port, but packets to different
destinations travel on different ports in the channel.
• srcDstlp—bases load distribution on the IP address of the
source logic gate (XOR) destination.
Trunk Group Enabled field Displays a checked Enable checkbox to indicate an active trunk
group.
MTU field Displays the MTU of the group.
