DesignJet 2800CP
HP Parts Reference Guide™
www.h
.com/
o/h
arts
Paper and Other Media
Paper (Semi-Glossy)
C6024A Semi-gloss photo paper - 91.4cm (36in) x 30.5m (100ft) roll (USA, Canada, and Latin America)
C6783A Paper based semi-gloss media - 91.4cm (36in) x 30.5m (100ft) roll
NO LONGER SUPPLIED
Vinyl (Adhesive)
C6775A Colorfast adhesive vinyl (328 gsm) - 91.4cm (36in) x 12.2m (40ft) roll - For regular ink or UV-resistant ink
Roll Feed Parts
Brake/Housing
218
C4704-60199 Brake/housing assembly (on right side) - Accepts the flange end of the spindle rod assembly - Includes the 2 housing
pieces, 2 brake shoes, brake gear, brake lever, and springs
Cover
219
C4704-60312 Rollfeed access cover - Opens forward to allow access to paper spindle assembly
End Cap
220
C2858-40043 Spindle end cap (small) (or core spacer) - Removes for loading the media roll
Housing
221
C4704-60082 Housing assembly (on left side)
Spindle
222
C4704-60317 Rollfeed spindle rod assembly - Includes flange and core spindle spacer
Spring
223
C1633-80004 Extension spring - Holds the rollfeed access cover closed
© 2004 Hewlett-Packard 10
