TFTP configuration file
To provide additional configuration parameters for your HP Jetdirect print server, such as SNMP (Simple Network
Management Protocol) or non-default settings, an additional configuration file can be downloaded using TFTP. This
TFTP configuration file’s relative path name is specified in the BOOTP reply using the vendor-specific tag “T144” or
the standard BOOTP tag “ef” in the /etc/bootptab file.
Example of a TFTP configuration file. Lines starting with “#” are remarks not included in the file.
#
# Example of an HP Jetdirect TFTP Configuration File
#
# Allow only Subnet 192.168.10 access to peripheral.
# Up to 10 "allow" entries can be written via TFTP.
# Up to 10 "allow" entries can be written via Telnet or embedded web server.
# "allow" may include single IP addresses.
#
allow: 192.168.10.0 255.255.255.0
#
#
# Disable Telnet.
#
telnet: 0
#
#
# Enable the embedded web server.
#
ews-config: 1
#
#
# Detect SNMP unauthorized usage.
#
authentication-trap: on
#
#
# Send Traps to 192.168.10.1.
#
trap-dest: 192.168.10.1
#
#
# Specify the Set Community Name.
#
set-community-name: 1homer2
#
# End of file
TFTP configuration file parameters
The following types of TFTP parameters are listed and described in tables below. You can click on a category below, to
jump to the list.
General parameters●
TCP/IP: main parameters●
TCP/IP: print option parameters●
TCP/IP: raw print port parameters●
TCP/IP: access control parameters●
TCP/IP: other parameters●
SNMP parameters●
IPX/SPX parameters●
AppleTalk parameters●
DLC/LLC parameters●
