GNC 420(A) Pilot’s Guide and Reference
5-8
SECTION 5
FLIGHT PLANS
• ‘Sort List By Number?’/’Sort List by Comment?’
- Allows the pilot to sort numerically by the ight
plan number or alphanumerically based upon the
comment assigned to each ight plan. When one
option is selected, the other option appears on the
Flight Plan Catalog Page Menu.
Sorting the catalog listing by number or
comment:
Select the ‘Sort List By Number?’ or ‘Sort List
By Comment?’ option (whichever is currently
displayed) from the Flight Plan Catalog Page
Menu (Figure 5-18) and press the ENT Key.
Figure 5-18 Flight Plan Catalog Page Menu
5.2 ACTIVE FLIGHT PLAN PAGE
The Active Flight Plan Page provides information
and editing functions for ‘ight plan 00’, the ight plan
currently in use for navigation. Once the pilot has
activated a direct-to or ight plan, the Active Flight Plan
Page shows each waypoint for the ight plan (or a single
waypoint for a direct-to, Figure 5-19), along with the
desired track (DTK) and distance (DIS) for each leg.
Figure 5-19 Active Flight Plan Page
Active Flight Plan Options
The options shown in Table 5-1 are available for the
Active Flight Plan Page.
Accessing the Active Flight Plan Menu Page:
1) Press the FPL Key to view the Active Flight Plan
Page.
2) Press the MENU Key (Figure 5-20).
Figure 5-20 Active Flight Plan Page Menu
190-00140-20 Rev. K
