SW DVI A Series • SIS Conguration and Control
SIS Configuration and Control, cont’d
4-4
SW DVI A Series • SIS Conguration and Control
4-5
Command ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Input selection
Select video and audio input
X!
! In
X!
All
]
Select both audio and video inputs
X!
.
Select video input only
X!
& In
X!
Vid
]
Select video input
X!
.
Select audio input only
X!
$ In
X!
Aud
]
Select audio input
X!
.
Input video signal sensing
Request status of all inputs 0LS
Sig
X@
•
X@
•
X@
•
X@
]
X@
= input signal status:
1 = present; 0 = not present.
N
This command is case-sensitive.
Request status of an individual
input
X!
LS
X@
]
N
This command is case-sensitive.
Video muting
Video mute
X@
B Vmt
X@
]
Mute the video signal.
Read video mute B
X@
]
Show video muting status
X@
:
1 = muted, 0 = unmuted.
Audio muting
Audio mute
X@
Z Amt
X@
]
Mute the audio signal.
Read audio mute Z
X@
]
Show audio muting status
X@
:
1 = muted, 0 = unmuted.
Front panel lockout
Enable/disable executive mode
X@
X Exe
X@
]
For
X@
: 1 = front panel locked;
0 = front panel unlocked (default).
Lockout status X
X@
]
Show executive mode on/off status.
Command/response table for SIS commands
Command ASCII Command
(host to unit)
Response
(unit to host)
Additional description
IR receiver disable from front panel
Enable/disable IR receiver
X@
* 65# IRDisable
X@
]
Disable the IR remote receiver on the front panel
from receiving signals from the IR remote control.
IR status 65#
X@
]
View IR receiver status. For
X@
, 0 = off, 1 = on.
Firmware version, part number, and information requests
Request information I
V
X!
• A
X!
• Vmt
X@
• Amt
X@
]
Show the selected video and audio input numbers,
and the video and audio muting status.
Request part number N
60-840-xx
]
Show switcher part number.
SW2 = 60-840-01, SW4 = 60-840-02.
Query rmware version Q
X#
]
Show rmware build number
X#
, expressed to the
second decimal place.
Example:
Q
1.01
]
Query EQ DIP switch status 41S
Dip
X@
•
X@
•
X@
•
X@
]
X@
= DIP switch status for each input.
1 = on (up); 0 = off (down).
N
This command is case-sensitive.
Query autoswitch mode 72#
Asw
X@
]
Show on/off status of autoswitching.
For
X@
: 0 = disabled, 1 = enabled.
Reset
Reset
E
ZXXX
}
Zpx
]
Reset the switcher to factory default values.
Upload firmware
Upload rmware
E
Upload
}
...go
Upl
]
Upl appears after upload is complete.
Command/response table for SIS commands (continued)
