4-13
IPL 250 • SIS Programming and Control
Command/response table for SIS commands (continued)
Command ASCII (Telnet)
(host to IPL)
URL Encoded (Web)
(host to IPL)
Response
(IPL to host)
Additional description
Query bootstrap firmware
version
2Q 2Q
X1! ]
or Ver02*
X1! ]
The bootstrap firmware is not user-
replaceable, but you may need this
information during troubleshooting.
Example:
2Q 2Q
2.20
]
Query factory firmware version 3Q 3Q
X1!
(kernel version–model description–date time of upload)
]
or Ver03*
X1!
(kernel version–model description–date time of upload)
]
Factory-installed firmware is different from
the bootstrap firmware, but it is also not user-
replaceable. This firmware was installed at
the factory; it is the version the controller
reverts to after a mode 1 reset (see chpt. 2).
Example:
3Q 3Q
1.14(1.77-IPL Series -Wed, 16 Jan 2003 00:00:00 GMT)
]
In this example the factory firmware version
is 1.14 and the IP Link kernel version is 1.77
for the IPL 250, dated 16 January 2003.
Query updated firmware version 4Q 4Q
X1!
(kernel version–model description–date time of upload)
]
or Ver04*
X1!
(kernel version–model description–date time of upload)
]
Use this command to find out which version
of the firmware, if any, was uploaded into
the controller after it left the factory
Example:
4Q 4Q
1.15*(1.78-IPL Series -Fri, 17 Jul 2009 21:47:29 GMT)
]
In this example the current firmware version
is 1.15, the IP Link kernel version is 1.78, for
the IPL unit, and the last firmware upload
was on July 17, 2009.
N
Responses to commands differ depending on which, if any, verbose response mode the IPL is in. See the CV command (
E
X2@
C V
}
) under IP setup commands later in this table.
Request the IPL’s part number N N
60-1026-81
]
or Pno 60-1026-81
]
Show the IPL’s part number.
Request the model name 1I 1I
IPL•250
]
or Inf01*IPL 250
]
IPL 250.
Request the model description 2I 2I
Three Bi-Directional Serial Ports [RS232], Four Contact Input Ports, Four Relay
Ports, Four IR Ports, IR Learner
]
or Inf02* Three Bi-Directional Serial Ports [RS232], Four Contact Input Ports,
Four Relay Ports, Four IR Ports, IR Learner
]
