EPSON EB-826W/ 826WV New Product Summary (02.06.2009)
Specifications
Projection system (3LCD)
0.59” with MLA
Native resolution
WXGA (1 280 x 800)
Native aspect ratio
16:10
Resolution supported
VGA ~ UXGA / WSXGA+
Color Light Output
2500 lm (Color mode: Game)
White light output (Brightness) *
2500 lm (Color mode: Game, Zoom: Wide)
Projection lens
Throw ratio
1.38 – 2.24: 1
Image size
60" screen 1.81 - 2.92 m
Focal Length / F
Number
18.2mm-29.2mm / 1.49-1.94
Focus/Zoom type
Focus (Manual) / Optical Zoom (Manual) 1.6x
Offset
10:0
Lens protection
Slide lens shutter
Lamp Type
200 W UHE (E-TORL)
Life
5000 hours (Brightness Control: High) / 6000 hours (Brightness Control: Low)
Colour Reproduction
Full-color (16.77 million colors)
Fan noise
28 dB / 35 dB (Eco / Normal mode)
Contrast ratio *
2000:1 (Color mode: Game, Brightness Control: High, Zoom: Wide, Auto iris: On)
Screen size (Projection distance)
29" to 280" [0.84 to 8.7 m] (Zoom:Wide)
29" to 280" [1.36 to 13.9 m] (Zoom:Tele)
Adjustment Function Foot Adjuster
Front-centre
Tilt Angle
0 to 11 degrees
Keystone Correction
Vertical: PC -30 to +30 degrees (Zoom: Tele)
Auto Keystone
Correction
Yes
Source Search
Yes
Auto Detection of
RGB/Component
Yes
Operation Panel
Protected Function
Yes
Sleep mode
Yes
Input Connections Computer
2xD-sub 15-pin (RGB)
Video
1 x D-sub 15-pin (component), 1 x D-sub 15-pin (RGB)1xRCA (yellow), 1x S-Video, 1 x USB Type B
Audio
2xStereo mini-jack, 1x RCA (Red/White), 1x Microphone mini-jack input
Control
1x USB Type B
1x RS232 C (D-Sub 9 pin male)
Network
LAN via RJ45
USB Type A
USB Type A x 1 (for USB Memory, Document Camera)
Output Connections
1xD-sub 15-pin (RGB)
1xStereo mini-jack
Built-in speaker
10 W monaural
USB Display
Yes
Direct Power On/ Instant Off
Yes
Security
Kensington lock hole & Security Cable Hole
Wireless Specification
IEEE 802.11b: 11 Mbps*
IEEE 802.11g: 54 Mbps*
IEEE 802.11a: 54 Mbps*
*Maximum speed and range is achievable when used with same enhanced mode technology.
Wireless LAN Security
WEP,WPA-PSK(TKIP/AES),WPA2-PSK(TKIP/AES)
Other functions
Direct power On / Power Off
Quick start : ~5 secs. - Instant Off
EMP Monitor for LAN monitoring
Operating temperature / altitude
5 °C to 35 °C <41 °F to 95 °F> ( 20%-80% Humidity ) / 0 m to 2286 m<0 ft to 7500 ft>
Power supply wattage
100 - 240 V AC ±10%, 50/60 Hz
Power consumption lamp on
300W
Power consumption stand-by
5W (network off) / 12W (network on)
