RTM-ATCA-SXXX Mechanical and Connector Information
6806800H62B ATCA-S201ATCA-S201 Installation and Use Guide 130
Table 60 Environmental Specifications for the ATCA-S201
SPECIFICATION VALUE
Operating Temperature (airflow 3.1 CFM) 0°C ~ 55 °C
Storage Temperature -40 °C ~ 85 °C
Operating Temperature Gradient 11 °C /H (max)
Storage Temperature Gradient 20 °C /H (max)
Shipping Temperature Gradient 20 °C /H (max)
*1
Operating Humidity 8 % ~ 80 %
Storage Humidity 5 % ~ 95 %
Shipping Humidity 5 % ~ 95 %
*1
Wet bulb Maximum Temperature 27 °C
Condensation No condensation
Atmospheric Pressure and Altitude
Operating: 0 ~ 3,000 m
Shipping: 0 ~ 12,000 m
Operating Shock
See PICMG 3.0 specification, Regulatory
guidelines.
Operating Vibration See PICMG 3.0 specification, Regulatory
guidelines.
RoHS 6 of 6 compliant.
13.1.4 NEBS Compliance
NEBS certifications are performed by integrator at a system level (chassis, ATCA,
AMC shelf managers etc). The RTM module will not preclude the system form
passing NEBS.
13.1.5 Electromagnetic Compliance
The board is designed and implemented so as to minimize electromagnetic
emissions, susceptibility, and the effects of electrostatic discharge. The board
carries the following certifications:
