25HP Electrical Assembly Kawasaki
- Parts List for Figure 24
Ref.
No. Part No. Description Qty.
1 00012032 Battery, 12V 225CCA 30 Min 1
2 00012152 Lock Nut w/Nylon Insert 2
3 00012165 Nylock Nut, 5/16-18 2
4 00012470 Tie, Cable, 3/16 x .05 x 7.4" 5
5 00013131 Screw, Hex, Cap, 1/4-20 x .75 4
6 00013258 Boot, 1" OD Rubber Battery-PST, Red 1
7 00014608 Nut, Lock, Nylon Insert, #10-32 2
8 00030906 Screw, Phillips Head, Machine, 10-32 x 5/8 1
9 00032097 Nut, W/Cap, 5/8-32 Ignition 1
10 00095773 Cable, Battery, Red, 15" 1
11 01000628 Screw, TT, 1/4-20, 0.5, Hex Index Washer 2
12 01001811 Hourmeter, Harness (not shown) 1
13 01002111 Switch, Electric, PTO 1
14 01002228 Solenoid Magnetic Switch 1
15 01002766 Hex Flange Lock Nut, 1/4-20 2
16 01003581 Switch, Ignition, 6 Pin 1
17 01003649 Strap, Battery 1
18 01004040 Grommet, .75 ID 1
19 01004078 Cable, Battery Black, 28" 1
20 01005389 Meter, Hour 1
21 01005406 Cable, Battery Red, 32" 1
22 01008042 Spring Retainer 1
23 01009905 Bracket, PTO Switch Retainer 1
24 01009995 Mount Bracket, Battery 1
25 02000024 Switch, Safety N.O./N.C. 2
26 02000165 Switch, Plunger 1
27 02000591 Harness Assembly (not shown) 1
28 02000349 Bracket, Plunger Switch 1
29 02000348 Clamp, Plunger Switch 1
30 01002251 Relay, 12V 40A 1
