COLORstrip™ Mini User Manual 12 1/26/2010 2:49 PM
Re-initialize fixture
Re-establishes correct number of down-link fixtures for sequential chase runs.
Master/Slave & Stand Alone
The Master/Slave mode will allow you to link units in a daisy chain fashion. In this mode, the first unit
in the daisy chain will command all other units following. Stand Alone can simply be achieved by
setting all units to Master. They would no longer be required to be linked in series.
Built in programs detailed
P = Run speed
F = Flash speed
Sequential color chase patterns
Use sound sensitivity rotary knob to adjust sound
level for optimum response or decrease sensitivity
completely to operate in Run speed only
P = Run speed
MASTER UNIT Settings
Press the Mode button. Then, by using the
Up/Down buttons, select [ ] and press the Enter
button.
Select programs by using the Up/Down
buttons. Press the Enter button.
Some programs have additional controls such as flash
and run speed. Press the Mode button to toggle
additional functions, then use the Up/Down
buttons to change values.
Refer to the Control Panel Modes & Functions
chart on the previous page.
IMPORTANT INSTRUCTIONS FOR MASTER/SLAVE OPERATION
Turn ON the Master unit last! This will assure that the Master unit will fully detect all linked units, and re-configure its
built-in sequential chase programs to run on the correct number of linked units.
SLAVE UNIT Settings
Units that follow the Master unit
will automatically synchronize to
the Master unit. No other
settings are required.
DMX signal output
does not continue
on M/S linked
fixtures.
