Appendix A
Technical Specifications
Hardware Specifications
Standard Compliance: IEEE802.3/802.3ab / 802.3z / 802.3u / 802.3x
Network Interface:
Configuration Mode Connector Port
10/100Mbps Fast Ethernet Copper NWay TP (RJ-45) 1 – 24
10/100/1000Mbps Gigabit Copper NWay TP (RJ-45) 25, 26
1000Base-SX Gigabit Fibre 1000 FDX *SFP 25, 26
1000Base-LX Gigabit Fibre 1000 FDX *SFP 25, 26
1000Base-LX Single Fibre WDM (BiDi) 1000 FDX *SFP 25, 26
*Port 25, 26 are Copper/SFP fibre dual media ports with an auto detect function
*Optional SFP module supports LC or BiDi LC transceiver
Transmission Mode: 10/100Mbps support full or half duplex
1000Mbps support full duplex only
Transmission Speed: 10/100/1000Mbps for Copper
1000Mbps for Fibre
Full Forwarding/Filtering Packet Rate: PPS (packets per second)
Forwarding Rate Speed
1,488,000PPS 1000Mbps
148,800PPS 100Mbps
14,880PPS 10Mbps
MAC Address and Self-learning: 8K MAC address
256K VLAN Table Entries
256K IP Multicast Table Entries
Buffer Memory: Embedded 256 KB frame buffer and 128KB control memory.
