OPERATION MANUAL
NAV-402AP-3
TABLE OF CONTENTS
Page 1
Sep 1/04
CHAPTER ONE
NAV-402AP-3 TEST SET
OPERATION MANUAL
TABLE OF CONTENTS
Title Chapter/Section/Subject Page
SECTION 1 – DESCRIPTION 1-1
1. General Description and Capabilities 1-1-1 1
1.1 Description 1-1-1 1
1.2 Functional Capabilities 1-1-1 1
SECTION 2 – OPERATION 1-2
1. Installation 1-2-1 1
1.1 General 1-2-1 1
1.2 Battery Operation 1-2-1 1
1.3 Battery Charging 1-2-1 1
1.4 Safety Precautions 1-2-1 1
1.4.1 Complying with Instructions 1-2-1 1
1.4.2 Grounding Power Cord 1-2-1 1
1.4.3 Operating Safety 1-2-1 1
1.4.4 CAUTION and WARNING Labels 1-2-1 1
1.5 AC Power Requirements 1-2-1 2
1.6 FCC Requirements 1-2-1 2
1.7 Battery Recharging 1-2-1 2
1.8 Bench Operation 1-2-1 3
1.9 External Cleaning 1-2-1 3
2. Controls, Connectors And Indicators 1-2-2 1
2.1 Front Panel 1-2-2 3
2.2 Rear Panel 1-2-2 8
3. General Operating Procedures 1-2-3 1
3.1 General 1-2-3 1
3.2 Signals Simulated 1-2-3 1
3.3 Operation CAUTIONS 1-2-3 1
3.4 Ramp Operation 1-2-3 1
3.5 Bench Operation 1-2-3 2
3.6 Counter Operation 1-2-3 2
3.7 Battery Parameters 1-2-3 2
3.8 Operate LOC and G/S Simultaneously 1-2-3 2
3.9 Marker Operation (Typical Control Settings) 1-2-3 3
3.10 VOR Operation (Typical Control Settings) 1-2-3 4
3.11 Localizer Operation (Typical Control Settings) 1-2-3 5
3.12 Glide Slope Operation (Typical Control Settings) 1-2-3 6
3.13 Communication Operation (Receiver Tests)
(Typical Control Settings) 1-2-3 7
3.14 Communication Operation (Transmitter Tests)
(Typical Control Settings) 1-2-3 8
