Conair GMT170ACS Electric Shaver User Manual



OPERATING
INSTRUCTIONS FOR
YOUR TRIMMER
1. Remove the battery compartment cover by
pushing in and down toward the bottom of the
trimmer.
2. Align the two AA batteries with the positive and
negative positions indicated inside the battery
compartment. Being careful not to bend the clips,
insert the negative end of each battery first so it
will slip easily into position.
3. Return the battery cover to its original position
by pushing it in and up until you hear a small
springs as it locks into place.
4. To use your trimmer, push ON/OFF switch
upwards to ON position.
5. After you finish using your trimmer, push
down on the ON/OFF switch to turn the trim-
mer off.
6. For your convenience, the trimmer comes
with a storage pouch to hold the trimmer and
accessories.
*Requires 2 AA batteries (not included). We recommend using
alkaline batteries in your trimmer because they last longer.
GROWING A BEARD
AND MUSTACHE
There are three key factors that determine
which beard or mustache style is most
suitable for your face:
1. The shape and dimensions of your face.
2. The natural growth of your beard/mustache.
3. The thickness of your beard/mustache.
If you are unsure of the type of beard or
mustache that most suits your face, speak with
a professional hair stylist and ask for an opinion
on what style would be best. Once your beard
or mustache has been styled, it is essential
that you maintain its appearance. To do this,
use your shaper to trim, edge and line up your
beard/mustache weekly.
For the best trimming results, your beard should be
slightly damp (not wet) before using the trimmer.
This will prevent the trimmer from removing more
hair than desired.
TYPES OF BEARDS/MUSTACHES
There are several things to look for if your
trimmer fails to operate:
1. Be sure the trimmer is turned ON.
2. Make sure that the batteries are properly
placed in the battery compartment. Test the bat-
teries to be sure they are working. (For optimum
trimmer operation, always replace all two AA
batteries at the same time.)
3. Check the blades to see if they are clogged
with hair clippings; if so, use the cleaning brush
to remove hair.
4. If the trimmer still fails to operate, take or
send it to a Conair Service Center (see warranty
procedure and addresses).
TAKING CARE OF YOUR TRIMMER
OILING THE BLADES
About once a month you should oil the
trimmer blades with the oil provided in your
kit. It is best to do this over a piece of newspa-
per. Turn the trimmer on and hold it so that the
blades are pointed downward. Spread one drop
of oil across the blades, then turn the trimmer off
and wipe away the excess oil with a soft cloth.
Be careful not to use too much oil and don’t oil
your trimmer more than necessary, as that could
damage the motor. (Never attempt to oil the
motor bearing as it is permanently lubricated.)
After oiling the blades, replace the trimmer and oil
packet in the trimmer storage pouch.
BLADE CARE
Because the trimmer blades are precision made
for a very special use, they should always be
handled with care. Each time you finish using the
trimmer, take the cleaning brush provided and
brush away any loose hair that has collected in
the blades. Then store the trimmer in its storage
pouch until the next use.
Be especially careful when changing or adjust-
ing blades. When you have your trimmer ser-
viced, be sure that all blades are sharpened or
replaced at the same time.
To promote the long life of the appliance, use
your trimmer only for the purpose intended
by the manufacturer—to trim your beard and
mustache.
GETTING STARTED
OUTLINING YOUR BEARD
1. It is always best to begin with a clean, slightly
damp beard.
2. After you have combed through your beard in
the direction it grows naturally, you will want to
outline the desired shape, beginning under your
jawline.
3. Begin defining your beard’s shape under
your chin and work upward on each side of
your face toward your ears. Then define the
upper outline of your beard across your cheeks,
past your sideburns and toward your hairline.
INSTRUCCIONES
DE USO PARA SU
RECORTADORA
1. Remueva la tapa del compartimiento de las
pilas apretando y empujando hacia abajo del
recortador.
2. Alinee las 3 pilas “AA” (no incluidas)
con los indicadores de positivo y negativo
indicados en el compartimiento de las pilas.
Primero inserte el polo negativo de cada pila
para que entre fácilmente en su posición. Tenga
cuidado de no doblar los clips.
3. Vuelva la tapa a su posición original apretán-
dola hacia arriba hasta que oiga un pequeño clic
y quede asegurada en su lugar.
4. Para usar su recortador, presione el botón
de encendido hacia arriba a la posición de
ENCENDIDO.
5. Después de que termine de usar su
recortador, presione hacia abajo el interruptor
ENCENDIDO/APAGADO para apagar el recorta-
dor en la posición off.
6. Para su conveniencia el recortador viene con
una base guardatodo para el recortador y sus
accesorios.
* Requiere de 3 pilas “AA” de 1,5 volts (se incluyen).
Nosotros recomendamos usar pilas alcalinas en su
recortador porque duran más.
DEJANDO CRECER SU BARBA Y BIGOTE
Hay tres factores que determinan cuál es el
estilo de barba y bigote que son más acordes
a su cara:
1. La forma y las dimensiones de su cara.
2. La forma natural en que crece su barba o
bigote.
3. El grueso de su barba y bigote. Si usted no
está seguro del tipo de barba o bigote que va
más acorde con su cara, hable con un estilista
de un salón profesional y pregúntele su opinión
de qué estilo puede ser el mejor. Una vez que
su barba o bigote ha sido estilizado, es esencial
que usted mantenga su apariencia. Para hacer
esto, use su recortador y recorte su barba y bigote
semanalmente.
Para mejores resultados de recorte, su barba
debe estar limpia y ligeramente húmeda (no
mojada) antes de usar su recortador. Esto le
va a prevenir que recorte más cabello del que
usted desea.
TIPOS DE BARBA Y BIGOTE
Hay varias cosas que controlar si su recortador
falla en la operación:
1. Asegúrese de que esté prendido en la
posición ON.
2. Asegúrese de que las pilas estén colocadas
correctamente en su compartimiento. Pruebe
que las pilas estén funcionado. (para una óptima
operación de su recortador, siempre reemplace
las 3 pilas al mismo tiempo).
3. Controle que las cuchillas no estén conges-
tionadas con recortes de cabello, si es así, use el
Cepillo Limpiador para limpiarlas.
4. Si el recortador sigue fallando, tómelo y envíelo
a un Centro de Servicio Conair para su servicio y
reparación.
EL CUIDADO
DE SU RECORTADOR
ACEITANDO LAS CUCHILLAS
Aproximadamente una vez al mes usted debe
lubricar las cuchillas del recortador con el aceite
que está provisto en el juego. Es mejor aceitarlo
sobre un papel periódico. Prenda el recortador y
deténgalo con las cuchillas hacia arriba. Ponga
una gota de aceite a través de las cuchillas,
apague el recortador y limpie el exceso de aceite
con un trapo suave.
Tenga cuidado de no usar mucho aceite y de no
aceitarlo más de lo necesario pues esto puede
dañar el motor. (Nunca trate de aceitar el motor,
ya que éste se encuentra permanentemente
lubricado).
Después de aceitar las cuchillas, ponga su recorta-
dor y el aceite en su base guardatodo.
CUIDADO DE LAS NAVAJAS.
Las navajas han sido hechas con precisión para
un uso muy especial, siempre deben ser tratadas
con cuidado. Cada vez que termine de usar su
recortador tome el Cepillo Limpiador provisto y
limpie todo el cabello suelto que queda en las
cuchillas. Guárdelo en su base guardatodo hasta
su próximo uso.
Tenga cuidado cuando cambie o ajuste las nava-
jas. Cuando usted le haga servicio a su recortador
asegúrese de que las navajas estén afiladas o
cambiadas al mismo tiempo.
Para promover la larga vida de su aparato,
use su recortador sólo para el propósito para el
que está hecho por el fabricante – para recortar
su barba y bigote.
PARA COMENZAR
DELINEANDO SU BARBA
1. Siempre es mejor empezar con una barba lim-
pia y ligeramente húmeda.
2. Después de haber cepillado su barba en la
dirección que crece naturalmente, usted va a
querer alinear la forma deseada, empezando por
la parte baja de su mandíbula.
3. Empiece definiendo la forma de su barba debajo
de su barbilla y trabaje hacia arriba con cada lado
de su barba hasta sus orejas, después defina la
alineación de la parte alta de su barba cruzando
sus mejillas, empareje sus patillas hasta la línea
del cabello.
Battery Position
On/Off Switch
Posición para las pilas
Encendido/Apagado
Instructions for Care and Use
Model GMT170ACS
Beard &
Mustache
Trimmer
Instrucciones de uso
y mantenimiento
Modelo GMT170ACS
Recortadora
de Barba
y Bigote
08PG096_GMT170ACS_IB.indd 1 5/19/08 4:55:30 PM
