weaken the tank resulting in damage
from rupture or explosion. Always
replace worn, damaged or cracked
tanks.
• Release air pressure from
air tank by pulling safety
relief ring before
servicing or replacing
parts.
Wear
ANSI Z87.1-approved safety
glasses during operation to
avoid eye injury.
• For dry air only. Do not use to store
or disperse liquids or flammable
gases.
• Store inside. Do not store outside or
in direct sunlight.
• Only use attachments rated at 150
psi minimum.
• Check air hoses for weak or worn
condition before each use. Make
sure all connections are secure.
!
WARNING
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
Portable air tanks are high quality,
welded steel pressure vessels designed
to carry a supply of compressed air for
home, farm and automobile uses.
This tank does not
have ASME
certification. Before using, check local
and state code requirements.
Unpacking
When unpacking, inspect carefully for
any damage that may have occurred
during transit. Make sure any loose
fittings, bolts, etc., are tightened
before putting unit into service.
Safety Guidelines
This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
and to PREVENT EQUIPMENT PROBLEMS.
To help recognize this information,
observe the following symbols.
Danger indicates
an imminently
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
Warning indicates
a potentially
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
Caution indicates a
potentially
hazardous situation which, if not avoided,
MAY result in minor or moderate injury.
Notice indicates
important
information, that if not followed, may
cause damage to equipment.
NOTICE
!
CAUTION
!
WARNING
!
DANGER
NOTICE
Operating Instructions Models KTV008 and FHV009
IN287000AV 6/04
General Safety
Information
The following safety precautions must
be observed at all times:
Risk of explosion.
Failure to follow
warnings and instructions could cause
death or severe injury.
• Read all manuals
included with this
product carefully. Be
thoroughly familiar with
the controls and the proper use of
the equipment. Follow all
instructions.
• Only persons well acquainted with
these rules of safe operation should
be allowed to use the unit.
Never fill the tank
above 125 psi.
Personal injury or property damage
could occur.
Never fill from
bottled gas or any
air system which produces over 150 psi.
• Do not alter or tamper with the
safety relief valve. In the event that
the safety relief valve is tampered
with, existing warranties shall be
voided and Campbell Hausfeld
disclaims any liability whatsoever
for any loss, personal injury or
damage.
• This tank is stamped with a
“DISCARD AFTER” date located on
the handle. Discard tank and do
NOT use after this date has passed.
Replace with new tank.
NEVER
attempt
to repair or modify a tank.
Welding, drilling or any
other modification will
!
DANGER
!
DANGER
!
DANGER
!
DANGER
BUILT TO LAST
Air Carry Tank
© 2004 Campbell Hausfeld/Scott Fetzer
Breathable Air Warning
This tank is not equipped and
should not be used to supply
breathing quality air.
!
DANGER
MANUAL
For parts, product & service information
visit www.chpower.com
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
See Warranty on page 5 for important information about commercial use of this product.
DISCLAIMER OF WARRANTIES
In the event the tank is used for the
purpose of breathing air
application, existing warranties
shall be voided, and Campbell
Hausfeld disclaims any liability
whatsoever for any loss, personal
injury or damage.
