Filter
Top Products
SEL
ESC
Adjust
2
3 6
1
5
4
SDI
LOGO
FRZ BLACK
TAKE
Effects
PDS-902
PROGRAM: RGB
NEXT: SDI
1024x768@59.94
NTSC (480i)
Inputs
7 8
Quick Setup and Operations
1
Connect Power — Ensure that power is properly
connected to the PDS. (Chapter 3, “Cable and
Adapter Information”)
2
5
6
Barco, Inc.
Connect Outputs — Connect the output(s) of the
PDS to your projector(s) or other target devices.
(Chapter 3, “Signal Installation”)
Power On — Turn on power to the PDS, your
projector(s), and to all peripheral equipment.
(Chapter 4, “Power-Up Initialization”)
8
Set Output Format — Set the desired output
resolution and frame rate. (Chapter 4, “Output
Format”)
9
Save Output Configuration — After completing all
output adjustments, save the output configuration.
(Chapter 4, “Save Config”)
11
Enable Test Pattern — Turn on a test pattern, verify
an image, and adjust as required. When complete,
turn off the pattern. (Chapter 4, “Test Pattern”)
Select and Adjust Input — Select an input, and
perform the necessary image adjustments. (Chapter
4, “Input Menu”)
12
Adjust System Parameters — Adjust parameters
such as transition time, display brightness, user prefs.
(Chapter 4, “User Preference Menu,” “System Menu”)
13
14
3
4
Repeat for Each Input — Repeat steps 10 and
11 for each input that you have connected to the
PDS.
10
Save System Configuration — After completing all
system adjustments, save the system configuration.
(Chapter 4, “Save System State”)
15
Ready to Roll — With all output, input and system
configurations saved, press the desired input button,
and press TAKE.
16
7
Connect Inputs — Connect all analog, DVI, and
SDI input sources to the PDS. (Chapter 3, “Signal
Installation”)
Launch GUI — (Optional) Connect your laptop to the
PDS, log onto the PDS using its IP address, and
launch the GUI. (Chapter 5, “GUI Operations”)
Save Input Configuration — After completing all
adjustments for an input, save the input configuration.
(Chapter 4, “Save Config”)
Enable Remote Control — (Optional) Connect
Ethernet or Serial communications, and issue desired
commands. (Appendix B, “Remote Control”)
P/N 26-1204004-00 Rev 01
Inputs Section
Sources 1-4: Analog
Sources 5-8*: DVI or Analog
SDI: 3G/HD/SD-SDI
LOGO: Full screen capture
* (sources 7-8 not on PDS-701)
Menu Display
Use ADJUST knob,
plus SEL and ESC
buttons to navigate
menus.
Adjust
• Counter-clockwise: scroll down
menu tree, or decrement values.
• Clockwise: scroll up menu tree,
or increment values.
SEL
Press to enter a menu,
change or accept a
parameter, or answer
“Yes” to a query.
ESC
Press to exit a menu
without making changes,
cancel an operation, or
answer “No” to a query.
FRZ
Press to freeze or
un-freeze current
Program source.
Lit solid = frozen.
Button States
Off: Input not selected
Blinking: Input “pending” for transition
Lit solid: Input on Program
BLACK
Press to pend or initiate a black transition.
Black Auto Take mode affects function
(User Preferences). Blinking = Pending.
Lit solid = Black on Program.
TAKE
Press to mix the selected input
to Program, or to execute a pending
black transition. Use the Setup Menu
to adjust the transition time.
NOTE
After each
TAKE, Program
and pending
sources flip-flop.
Factory Reset – When using a PDS for the first
time, perform a factory reset. (Chapter 4,
“Factory Reset Menu”)
The following list summarizes PDS setup and
operations. For error-free installation, always
refer to the listed section in the User’s Guide.
PDS Series
Quick Start Guide
Visibly yours
Toll Free:
Fax:
Technical Support:
Website:
+1 (888) 414-7226
+1 (916) 859-2515
+1 (866) 374-7878
www.barco.com
