REPLACEMENT PARTS
Replacement parts are available, and may be purchased through our
Consumer Relations Department by calling 1-800-934-7455, Mon-Fri.
9am-5pm Central Time, with Visa, Mastercard, Discover, or American
Express. Please be ready to give the part number(s) when you call.
Or log into our website to order at: www.eSalton.com
Andrew Collinge 1875W
TRAVEL
HAIR DRYER
(AC1875THD) REPLACEMENT
PARTS
P
ART # DESCRIPTION
50541 Concentrator
50540 Air Filter Cover
The Air Filter is located at the
back of the dryer.To remove the
Filter Cover, hold on to the dryer
handle and lift the tab at the base
of the Filter Cover with the thumb
of your other hand until it
releases. Locate the tab at the top
of the Filter Cover and slide the
tab away from the dryer to
remove the cover. (Fig. A)
Use a small dry cloth to remove
build up from the Air Filter and
Filter Cover.
To replace the Filter cover, insert
the uppermost tab into the top
groove at the back of the dryer
until it locks in.(Fig. B) Press the
back of the Filter Cover until the
bottom tab snaps into place.
Note: Do not use the dryer without the Filter Cover.
Fig. A
Fig. B
AC1875THD.qxd 9/18/2003 4:12 PM Page 10
