P3 International E9350 Thermometer User Manual



SPECIFICATIONS
FEATURES
P3 INTERNATIONAL 132 NASSAU STREET NEW YORK NY 10038-2400 USA T +1 212 346 7979 F +1 212 346 9499 P3INTERNATIONAL.COM
COPYRIGHT © 2003 P3 INTERNATIONAL rev. 1/05
P3 INTERNATIONAL
INNOVATIVE ELECTRONIC SOLUTIONS
Functional:
The protective cap that protects
the wind wheel against damage
in transport can also be used
to provide a secure mount for
the unit.
E9350
Handheld Wind Meter
With Thermometer
Stationary wind meters have not always been
available at all sites where they are needed, such
as sites for ying model aircraft, para-gliding,
sailing, surng and many other leisure activities.
In addition to the excellent portability provided by
its compact design and the innovative “packaging”
of the wind wheel, the new ELV handheld wind
meter permits not only determination of the wind
strength, but also the complex assessment of the
weather situation at the site. Short-term changes
can be understood more quickly using the analog
bar graph display rather than the digital display.
The wind strength can be displayed in knots,
km/h, miles/h, m/s or Beaufort as desired, with
the temperature either in ˚C or ˚F, or alternatively
as a wind-chill equivalent (“sensed temperature”).
The latter display is very useful as it enables you
to make a real evaluation of the heat loss of the
human body when subject to wind, and therefore
prevent hypothermia. In this respect operation of
the hand-held device with only two large keys is
especially simple. The protective cap that protects
the wind wheel against damage in transport can
also be used as a stand for the device when in
operation, so that a rm and secure mounting is
provided. For battery conservation the device has
an automatic battery disconnect.
The large LCD display shows simultaneously
The wind strength in digital and quasi-analog form
The max. or average wind speed
The temperature at the site and
The min. or max. temperature as required.
Protective cap
Automatic battery disconnect
Wind strength:
Measuring range: ........................................................0 to 124 mph
Resolution:max....................................................................0.1 mph
Accuracy:..................................................................................±5 %
Voltage supply: ....................................................................2 x AAA
Temperature:
Measuring range: ..........................................................-4 to 150 ˚F
Resolution: .................................................................. max. 0.18 ˚F
Accuracy:.................................................................................. ±1 K
Dims. (HxWxD):..........................................................180 x 70 x 60
