HOISTS AND CRANES
SNER Electric Hoist
Recommended Spare Parts
1/4 to 3 Ton
This information describes the recommended spare parts for the ¼ to 3 Ton SNER Electric Hoist.
Refer to the Owner’s Manual for SNER Electric Chain Hoist complete parts list.
Hoist Capacity Code
Part Name
Parts Per
Hoist
003S 005L 005S 010L 010S 020L 030C
Brake Drum Assembly 1 ER1BS5212 EP1CS5212 ER1DS5212
Brake Spring 1 ER1BB9214 EP1CB9214 EP1DB9214
Nut 1 ES217005S ES217010S
Lock Washer 1 ES218005S ES218010S
Bottom Hook Complete Set 1 ER1BS1011 ER1CS1011 ER1CS1011 ER1DS1011 ER1ES1011 ER1DR1011
Cushion Rubber U (x)
ER1BS9053
(2)
ER1CS9053 (2) ER1DS9053 (2) ER1ES9053 (1)
U (x)
ES047015 (1)
ER1DL9051
(2)
Chain Spring
U/L
(x)
ES047D003
(2)
ES047A005 (2) ER1DS9051 (2)
ES047015 (2)
ER1DL9051
(3)
Start Switch 1 ECP99SS13 ECP99SS23
Capacitor Assembly w/
Resistor
1 EP1BS1473 EP1CS1473 EP1BS1473
Capacitor Assembly 1 ECP9911CP
Electromagnetic Contactor 1 MGC22306D MGC23306B
Push Button Cord Assembly 1 EP1BS1557 EP1DR1557
Fuse
- Trans. Secondary = 110V
1 9006271
In the column "Parts Per Hoist" a designator is used for parts that apply only to a particular model or option. The designators are:
U = Upper Limit Switch only (standard)
U/L = Upper/Lower Limit Switch (optional)
