Specifications - A
75
Ac Input Ratings and supplemental information
Model Agilent 6841A Agilent 6842A Agilent 6843A
Voltage Range (Vac)
87 - 106 Vac
104 - 127 Vac*
174 - 220 Vac
191 - 254 Vac
174 - 220 Vac*
191 - 254 Vac
180 - 254 V
L-L
(3Φ)*
342 - 456 V
L-L
(3Φ)
Maximum Input Current
(rms)
24 A (at 120 Vac)
28 A (at 100 Vac)
15 A (at 200/208 Vac)
13 A (at 230 Vac)
22 A (at 200/208 Vac)
20 A (at 220/230/240 Vac)
25 A per phase
15 A per phase
Input Power (max)
2500 VA/1400 W 3800 VA/2600 W 8900 VA/6550 W
Input Frequency
47 - 63 Hz 47 - 63 Hz 47 - 63 Hz
Net Weight
28.2 kg (62 lb) 32.7 kg (72 lb) 87.7 kg (193 lb)
Shipping Weight
31.8 kg (70 lb) 36.4 kg (80 lb) 127.3 kg (280 lb)
*input power configuration for the standard unit
IEC Mode Measurement System Characteristics for Agilent 6841A, 6842A, 6843A
Measurement Window Sample Rate Acquisition Window Acquisition Overlap
50 Hz operation
RECTangular
HANNing
12.8 kHz
8.533 kHz
320 ms (16 cycles)
480 ms (24 cycles)
None
50%
60 Hz operation
RECTangular
HANNing
15.360 kHz
7.680 kHz
266.7 ms (16 cycles)
533.3 ms (32 cycles)
None
50%
